12Kw Diesel Genset 2 Cylinder AC Three Phase Super SilentDiesel Generator
Product describition
| | Model | PD15ST3 (Silent Type) |
| Genset | Rated frequency (Hz) | 50 60 |
| Rated voltage (v) | 400 416 |
| Rated power (Kw/Kva) | 11/14 12/15 |
| Max power (Kw/Kva) | 12/15 12.5/16 |
| Rated current (A) | 16.7 18.2 |
| Phase number | Three phase |
| Power factor | 0.8 |
| Sockets + Teminal | 1 x 32A |
| Battery (Ah) | 36.0 |
| Fuel tank capacity (L) | 28 |
| Running Time (H) | 8 |
| Noise level dB@7m | 72 |
| Overall dimension (L*W*H)MM | 1300×700×870 |
| N.W/G.W(kg) | 320/ 345 |
| Engine | Engine Type | Diesel |
| Engine Model | 292F |
| Rated output(kw/rpm) | 14/3000 15/3600 |
| Structure type | 2-cylinder, in lined, 4-stroke, air-cooled |
| Staring system | Electric Start |
| Fuel consumption (L/h) | ≤4.1 |
| Displacement (ml) | 997 |
| Oil Capacity (L) | 3 |
| Alternator | 100% copper, brush type, self-excitation, AVR |
Why choose us:
Description:
Diesel engine is an internal -combustion engine, in which air is compressed to a sufficiently high temperature to ignite diesel fuel injected into the combustion chamber. It can be used to power diesel generator , water pump, tiller etc. Since the future emission standard demands, we are always improving the fuel and engine structures to reduce the impact on environment. "Green Engine" is our target. We always pay more attention to climate protection and environmental.
Package & Payment & Delivery Date & Warranty
Package: Plastic Package.
Payment: By 30 % T / T as deposit, 70% balance should be paid 10 days before shipment. Or 100 %L/C at sight.
Delivery: 25 days after we get the down payment.
Warranty: All Topower goods are warranted in accordance with our warranty terms for a period of12 months from date of despatch or 1000 running hours from date of commissioning whicheverdate occurs the sooner.
FAQ :
Q1: What is your warranty period?
A1: Our warranty period is 1 year or 1000 running hous, whichever comes first(Excep the damageable spare parts of genset caused by incorrect man-made operation).
Q2: Does your generator have global warranty?
A2: Yes. Global warranty service is available depending on the engines and alternators you choose. Please contact us for more details
Q3: What is your payment terms?
A3: T/T 30% advance payment, the balance 70% shall be paid before shipment.
L/C Irrevocable L/C at sight.
Q4: What is your delivery time?
A4: Our standard delivery time is 20 to 30 days. If you have urgent demand, the delivery will be shorter depending on the requirements. If you have special requirements, the delivery will be longer.
Q5: Can the generators be customized?
A5: Yes. Our generators can be customized depending on customer's detailed requirements. We can supply generators for rental business, home use, inudstrial projects, army projects, power station, etc. The generators we supply is suitable for indoor and outdoor use, lower and high temperature environment.
Q6: Can you use our logo?
6: Yes. For mass orders, we can use customer's logo instead of ours.
