220v - 690v 50kw Electric Deutz Generator 62kva Smartgen Controller

Name: 220v 690v 50kw Electric Deutz Generator 62kva Smartgen Controller
Brand: GPRO
Price: 1 USD

Buy cheap 220v - 690v 50kw Electric Deutz Generator 62kva Smartgen Controller product

Brand Name : GPRO

Model Number : PF-D62

Certification : ISO,CE Certification

Place of Origin : Jiangsu of China

MOQ : 1 SET

Price : Negotiation

Payment Terms : L/C, T/T

Supply Ability : 300 Set / Month

Delivery Time : 15 - 20 working day

Packaging Details : Plywood or Plastic packing

Output Power : 50KW

Frequency : 50/60HZ

Voltage : 220v - 690v optional

Engine : Deutz

Alternator : Stamford, Meccalte, Leroy Somer, Marathon, Wattek for optional

Controller : Deepsea, Smartgen, Harsen for optional

MCCB : ABB or Delixi

Cooling system : Water cooled

Genset type : Open type, Silent type, Container type, Trailer type for optional

ATS : Optional

Contact Now

220v - 690v 50kw Electric Deutz Generator 62kva Smartgen Controller

GENERATOR SET
Genset model	PF-D62
Prime power (KW/KVA)	50/62.5
Standby power (KW/KVA)	55/69
Frequency & voltage	400V, 50HZ
No. of Phase	3
Genset type	Open skid type
Reference Dimension & Weight (W*H, mm)/KGS	20508501550;1000kgs
DIESEL ENGINE
Engine brand & Model	DEUTZ TD226B-4D
Rated output	60KW
Rated Speed	1500RPM
Engine Type	In-line, direct injection, four stroke
No. of cylinder	4
Bore*stroke	105*120mm
Aspiration method	turbocharged
Governor	Mechanical/Electrical
Starting method	Electric starting
Cooling method	Forced water cooled
Displacement	4L
Fuel consumption	208g/kw.h
Rotation direction of crankshaft	Counter clockwise(face to flywheel end)
ALTERNATOR
Alternator brand & model	Stamford/Leroy Somer/China reputed brand
Type	Brushless & self-excited
No. of phase	3
Volatage	400V
Frequency	50HZ
Power Factor	0.8
Insulation Grade	H
Protection Grade	IP22/23
Altitude	≤1000m

Deutz air-cooled power generation is to choose Beijing internal combustion engine co., LTD., the production of air-cooled engine matched brushless generator. Its characteristic is: low noise, low fuel consumption, small size, suitable for high elevations.

220v - 690v 50kw Electric Deutz Generator 62kva Smartgen Controller

Standard Supply Scope:
Generator set included: Diesel Engine, Brushless Alternator, Radiator, self-starting control panel, circuit breaker panel, Vibration damping pads, Hi-strength base frame
Accessories Included: industrial type silencer, flexible bellow, Elbow and Flanges, Starting Battery & battery charger, Battery switch with cables
Documents included: manual book, product qualified card

Optional supply scope:
1. ATS 2. SynchronizationSystem 3. External daily fuel tank 4. Silent Canopy 5. Trailer 6. Auto Fuel Pump 7. Fuel and Water Separator 8. Lub Oil Heater 9. Coolant Heater 10. Fuel Drain Pump

Advantages:
. A strong R&D team with rigorous selection and trainning
. Several years experiences in desinging and manufacturing diesel generator sets.
. Good reputation for reliable quality and reasonable price
. Advanced production line with skilled workers

Sales Promises:
. Our company provides a full line of brand new and high quality products which are strictly tested before shipment
. Quality warranty is according to our standard conditions: One year or 1000 running hours
